Full Vision Revolving Doors

Bauporte Doors UK

All-glass revolving doors by Bauporte have been developed into stable, always special entrances. The glass we use is from the best factories and if so desired, we can demonstrate them passing various burglar tests. The latest development is the special NSWA or NSWM wall. This system is a wall component during the day and a night-door by night. The glass top is supported by 4 pieces of pretty stainless steel pillars and the wall can slide under the top. Even more transparency and a very stable sealed edge, without any draft in the building front connection. The rotating component is all glass, and has stable glass clamps with stainless steel cross-connectors in the middle. If so desired Full Vision Revolving Doors meets Resistance Class RC 2, 3 and 4 of the EN 1627 classification and PAS 24. Even bullet and blast proof versions are available on request. Bespoke designs are the rule rather than the exception.


Properties

Recycled content (%)98
ReusableYes
Durability years30
Availability<2 months
Weight> 1000 kg
MaterialsStainless Steel base frame with a aluminium, SS, bronze or bespoke cladding. Aestheticall all glass design with minimal framing and glass roof. Manual or automatic operated.
FinishesAluminium, SS, bronze or bespoke cladding.
SizesDiameters > 1500 mm. Heights < 3000 mm. TALL Door versions > 3 meter up to 10 m.
ColoursAs desired.
Lifetime guaranteeYes
Other guarantees30-year guarantee with Gold a maintenance contract.
NBS clauseson request
BIMon request
CADon request

Endorsements

Be the first to endorse this product.

Add to Project Board

Create a new project board:

Accreditations

BS EN 16005 Safety in use. Power operated pedestrian doorsets. Requirements and test methods.BS EN 1627 Burglar resistance. Pedestrian doorsets, windows, curtain walling, grilles and shutters. Requirements and classification
