AluK GB Ltd's sliding and folding aluminium door systems provide a highly versatile way of bringing together indoor and outdoor spaces. Combining narrow profiles and high thermal efficiency, all of their systems create wide expanses that flood spaces with natural light, while maintaining internal temperatures and ensuring market-leading weather performance.

As with all AluK products, security is paramount. Concealed mechanisms, burglary-resistant locks and full testing and certification ensure our sliders and bifolds surpass industry standards.

SC156 Lift and Slide Door System

The premium SC156 Door has been designed to meeting the demands of projects that require the highest levels of thermal and weather performance. Delivering a U-value of 1.0W/m2K (triple glazed), alongside superior water tightness (1500Pa), this highly desirable system delivers enhanced capability without sacrificing style.

The narrow profiles feature a slim interlock of 50mm and have been specifically created to provide design flexibility by enabling larger glazing areas to be achieved. The system’s ‘lift and slide’ technology uses high quality fittings that ensure ease of operation whilst enabling panel weights of up to 400kg to be incorporated into designs.

The SC156 is PAS 24 accredited and available in a range of configuration and options.

Design Features:

• Lift & Slide technology for smooth operation
• Exceptional Air, Wind and Water ratings
• Low threshold of 23mm
• Maximum 400kg panel weight
• Slimmer sightline of 50mm interlock
• Mono or dual rail options
