SPIDI® Façade support system

Fixfast Ltd

The SPIDI® system gives you complete design flexibility and complete confidence – confidence in terms of both its engineering and its compliance.

  • It works with any substrate, panel or rainscreen material, and allows for any installation configuration. Put simply, it works in any application.
  • It meets all the necessary standards and compliance requirements.
  • It allows for cost effective installations thanks to the cost of the system itself, and through efficiencies when your installers are on site.
  • And it’s backed up by exceptional levels of technical and customer support from Fixfast.
    Fixfast setting a new standard for fixing façades with the SPIDI® System.

    System Overview
  • Highly versatile
  • Substructure
  • Speed of installation
  • Cost effective
  • Reliable technical advice
  • Fast turnaround

  • Suitable for any substrate, such as masonry wall, steel framing system, composite panel and timer frame. SPIDI® is a highly flexible support system for any type of rainscreen façade, regardless of cladding material and substrate. It is available in three ranges:

    SPIDI® Light

    SPIDI® Light has been designed with steel frame systems in mind. Strong and lightweight, it is ideal for new build projects in the UK. Brackets are available in steel or aluminium, in either small, medium or large widths, and with depths of between 40mm and 300mm. It also has an adapter which means the system can be used for horizontal applications.

    SPIDI® Heavy

    SPIDI® Heavy has been engineered for particularly heavy loads. This means it is suited for the slab-to-slab fixing often required on façade refurbishments where poor quality masonry infills mean the system must be able to span long distances. SPIDI® Heavy brackets are available in aluminium with depths of between 60mm and 270mm.

    SPIDI® Max

    SPIDI® Max offers maximum flexibility in terms of fixing to different substrates and the attachment of different rainscreen materials. Its bars and brackets allow for both vertical and horizontal installation configurations and are engineered with fixed and sliding points to accommodate expected movement in the façade.

    With brackets up to 900mm available, the system can be used for soffits, and easily copes with the heavy weight of rainscreen façades that other systems can’t. SPIDI® Max brackets are available in a range of sizes to allow for contoured elevations and to accommodate insulation thicknesses of between 65mm and 900mm deep. They are available in aluminium, coated steel, or stainless steel (either A2 or A4 grade).

    To find out more, visit the website here.
