Vaillant ecoTEC plus 48 and 64kW

Vaillant Group

Light commercial wall-hung boiler range

Vaillant's ecoTEC plus 48 and 64kW boilers are compact in size and lightweight, with the 48kW weighing as little as 38kg. These compact boilers are the perfect solution for projects that have tight, restrictive spaces to work in, especially as both the front and side panels can be removed, for much easier access. They can also be cascaded on a wall or rig system, offering a range of solutions for commercial installers who need a compact alternative to a much larger commercial boiler.

ecoTEC plus 48 and 64kW can also be converted to LPG to cater for projects that are unable to use a natural gas supply. A plate heat exchanger must be fitted when installing in cascade and the net output exceeds 70kW, or when fitting to old dirty or open vent systems thus ensuring no system dirt affects the boiler operation and maintains the efficiency for years to come.

Compact design
Smaller dimensions allow the boiler to be installed in tighter spaces

High efficiency stainless steel heat exchanger
ErP rated A the high efficiency heat exchanger enables lower running and ownership costs for end users

Rain ingress protection
Internal rain collector stops rain ingress from the flue system, preventing water depositing within the case and potentially damaging electrical components

Gunmetal air separator with system pressure gauge
Safely removes microbubbles from the system water thus improving the heat transfer within the boiler heat exchanger and ultimately improving efficiency.

Can be installed in cascade
Suitable for cascading in larger premises that have limited space

Full range of accessories available
Flues, plate heat exchangers and a full range of eBUS controls are all compatible
