Aluminium windows

Reynaers

The Concept System consists of CS24, CS38, CS59, CS68, CS77 and CS86. Each product offers various standards of thermal performance, security, functionality and aesthetics, from the slim line, steel replacement product, CS38 to the highly insulated CS86 HI.

The Eco System offers a solution for almost every standard application for windows and doors. One of the best performing systems in its price range, it combines aesthetic design with energy efficiency and comprises Eco50 and Eco75.

Within both ranges there are many opening types available, including the parallel opening window Airmax. Airmax allows greater airflow around all four sides of the window reducing the reliance on air conditioning whilst maintaining thermal performance. Reynaers windows also allow varying glass thicknesses with products that can incorporate triple glazing giving even greater thermal benefits. The CS104 window system has an industry leading Uw value of 0.77 Wm²K, making it the perfect solution for passive construction.

With our knowledge and experience in developing energy efficient systems, Reynaers can advise you on choosing the window system with the most suitable U value to help you meet the latest building regulations.


Properties

MaterialsCS 24 Slimline Windows
Aluminium frames with a glass fibre reinforced, polyamide thermal break

CS 38-SL Slimline Windows
Aluminium frames with a glass fibre reinforced, polyamide thermal break, dry-glazed with EPDM or neutral silicone gaskets.

CS 59 Concept System Windows
Aluminium frames with a glass fibre reinforced, polyamide thermal break.

CS 68 Concept System Windows
Aluminium frames with a glass fibre reinforced, polyamide thermal break, dry-glazed with EPDM or neutral silicone gaskets.

CS 77 Concept System Windows
Aluminium frames with a glass fibre reinforced polyamide thermal break, dry-glazed with EPDM or neutral silicone gaskets.

CS 86-Hi Concept System Windows
Aluminium frames with a glass fibre reinforced polyamide thermal break, dry-glazed with EPDM or neutral silicone gaskets

Eco75 Windows
Aluminium frames with a glass fibre reinforced, polyamide thermal break.

Eco50 Windows
Aluminium frames with a glass fibre reinforced, polyamide thermal break, dry-glazed with EPDM or neutral silicone gaskets.

FinishesPolyester powder coating is available in any standard RAL colour, or anodized finishes giving the appearance of stainless steel or wood. Different colours can be used internally and externally.
SizesCS 24 Slimline Windows
28 mm factory glazed double glazed units - Maximum thickness accommodated.

CS 38-SL Slimline Windows
33 mm factory glazed double glazed units - Maximum thickness accommodated.

CS 68 Concept System Windows
42 mm factory glazed double glazed units - Maximum thickness accommodated..

CS 77 Concept System Windows
51 mm factory glazed double glazed units - Maximum thickness accommodated.

CS 86-Hi Concept System Windows
62 mm factory glazed double glazed units - Maximum thickness accommodated.

Eco75 Windows
32 mm factory glazed double glazed units - Maximum thickness accommodated..

Eco50 Windows
32 mm factory glazed double glazed units - Maximum thickness accommodated.

ColoursStandard RAL colour. Different colours can be used internally and externally.
NBS clausesL10 Windows/ Rooflights/ Screens/ Louvres 330 ALUMINIUM WINDOWS
CADhttp://www.reynaers.com/uk/enuk/extranet/register.aspx
