Continuous Louvres & Louvre Panels

Renson Fabrications

Continuous Louvres

The continuous louvre system consists of a support structure to which blades are fitted. The support structure carries the complete louvre assembly and is formed by vertically or horizontal placed mullions fixed by brackets at set distances.

Depending on the structure, RENSON offers different mullion types. Blade supports are permanently fixed to the mullions allowing the blades to be clip-locked onto their supports. The method of construction is simple and well tested. Mitred corners, doors, vermin, bird or insect screens can all be incorporated.

Depending on the application, different constructions are possible.

Louvre Panels

All RENSON louvres panels have been manufactured from aluminium profiles AlMgSi 0,5 (according EN 12020-2). Aluminium is a very light metal, about one third of the weight of steel, this evolves in a lighter product, more efficient use of transport, high loading capacity, lower material usage.

The finished aluminium louvre is corrosion persistent. In order to improve this persistency, the louvre can be anodized or powder-coated. On top of that, aluminium is UV- resistant and can easily handle fluctuation in temperature. Aluminium is 100% recyclable without loss of quality and the energy used to fuse the product takes only about 5% of the energy used to produce the original product.


Properties

FinishesAnodized in satin/bronze colour (20 micron) or powder-coated in any RAL or Syntha Pulvin colour (40 micron).

For UK: Marine grade and special colour paint finishes available upon request.

Alternative anodising finsihes and thicknesses available upon request
