Modus 75mm Standard Sash Casement Windows
Modus is the first fully integrated PVC-U window and door system in the UK, capable of producing eight different product types from a single system. Its an innovative 75mm front to back dimension six-chamber design, the first to utilise dual material extrusion technology (DMET) in the UK. DMET precisely directs 50% virgin and 50% post-consumer recycled PVC-U into the profile simultaneously, with post-consumer material used only in the core of the profile, so finish quality and colour fastness is uncompromised. Thats why Eurocell can offer an unrivalled 12-year profiles guarantee for Modus.
Modus is a contemporary architectural design with a choice of no less than three casement window sash styles Standard, Slim Rebate and Flush a style to suit every type of building.
The Standard Sash option has a traditional PVC-U window aesthetic, which makes a feature of the window sash rebate, combined with slim sight lines thanks to the 55mm high outer frame profile.
Standard Product Features
High quality impact resistant white PVC-U extrusion utilising 50% post-consumer recycled PVC-U, producing a rigid six-chamber profile to BS EN 12608 and manufactured in accordance with BS EN ISO 9001 and BS EN ISO 14001.
Reinforcements are not required up to a 1600Pa weather classification. Between 1600Pa and 2000Pa a steel reinforcement is required in mullions.
Maco hardware accredited by ACPO Secured by Design, the official Police security standards initiative. Other hardware specifications can be provided.
Vents and casements are hinged using stainless steel friction hinges,
Locking and non-locking handles are available in a variety of finishes to complement exterior colours.
All hardware meets the requirements of BS 7412.
Windows fitted with high security hardware meet the requirements of PAS24: 2012
Windows are fitted with mushroom headed espagnolettes or shootbolts for added security. Both options are available with a night vent facility.
Controllable or permanent ventilators fitted within the head profile or dedicated overhead ventilators are available as an optional extra. Night vents are also available.
U-value performance of 0.7 for triple glazed windows, 1.1 U-value for double glazed windows.
Energy efficient windows, achieving BFRC Window Energy Rating (WER) of grades A+, A, B and C.
- Dummy Transoms
- Georgian bars
- Leaded glass
- Patterned glass
- Triple glazed units
28mm double-glazed insulating unit, glazed internally
44mm triple-glazed insulating unit, glazed internally
Cavalok head vent
